Texas Commission on Environmental Quality
Form OP-UA28 - Instructions
Polymer Manufacturing Attributes
General:
This form is used to provide a description and data pertaining to all polymer manufacturing facilities with
potentially applicable requirements associated with a particular regulated entity number and application. Each
table number, along with the possibility of a corresponding letter (i.e., Table 1a, Table 1b), corresponds to a
certain state or federal rule. If the rule on the table is not potentially applicable to a polymer manufacturing
facility, then it should be left blank and need not be submitted with the application. If the codes entered by the
applicant show negative applicability to the rule or sections of the rule represented on the table, then the
applicant need not complete the remainder of the table(s) that corresponds to the rule. Further instruction as
to which questions should be answered and which questions should not be answered are located in the
“Specific” section of the instruction text. The following is included in this form:
Table 1a - 1f:
Title 40 Code of Federal Regulations Part 60, Subpart DDD: Standards of
Performance for Volatile Organic Compound (VOC) Emissions from the
Polymer Manufacturing Industry
The Texas Commission on Environmental Quality (TCEQ) Regulated Entity Number (RNXXXXXXXXX) and
the application area name from Form OP-1 (Site Information Summary) must appear in the header of each
page for the purpose of identification for the initial submittal. The date of the initial form submittal must also
be included and should be consistent throughout the application (MM/DD/YYYY). Leave the permit
number blank for the initial form submittal. If this form is included as part of the permit revision
process, enter the permit number assigned by the TCEQ, the area name (from Form OP 1), the date of the
revision submittal, and the regulated entity number.
Unit attribute questions that do not require a response from all applicants are preceded by qualification criteria
in the instructions. If the unit does not meet the qualification criteria, a response to the question is not
required. Anytime a response is not required based on the qualification criteria, leave the space
on the form blank.
Notwithstanding any qualification criteria in the form instructions or information provided in
other TCEQ guidance, the applicant may leave an attribute question blank (or indicate “N/A”
for “Not Applicable”) if the attribute is not needed for the applicable requirement
determinations of a regulation for a unit.
In some situations, the applicant has the option of selecting alternate requirements, limitations, and/or
practices for a unit. Note that these alternate requirements, limitations, and/or practices must have the
required approval from the TCEQ Executive Director and/or the U.S. Environmental Protection Agency
Administrator before the federal operating permit application is submitted.
The TCEQ requires that a Core Data Form be submitted on all incoming registrations unless a Regulated Entity
and Customer Reference Number has been issued by the TCEQ and no core data information has changed. If a
Regulated Entity or Customer Reference Number has been issued, then the number must be noted on the
request or applicable form. For more information regarding the Core Data Form, call (512) 239 5175 or go to
the TCEQ Web site at:
www.tceq.texas.gov/permitting/central_registry
TCEQ-10048 (APDG5282v11, 01/14) OP-UA28 Instructions
This form for use by facilities subject to air quality permit requirements and
may be revised periodically (Title V Release 03/03)
Page 1 of 9
Texas Commission on Environmental Quality
Form OP-UA28 - Instructions
Polymer Manufacturing Attributes
General:
This form is used to provide a description and data pertaining to all polymer manufacturing facilities with
potentially applicable requirements associated with a particular regulated entity number and application. Each
table number, along with the possibility of a corresponding letter (i.e., Table 1a, Table 1b), corresponds to a
certain state or federal rule. If the rule on the table is not potentially applicable to a polymer manufacturing
facility, then it should be left blank and need not be submitted with the application. If the codes entered by the
applicant show negative applicability to the rule or sections of the rule represented on the table, then the
applicant need not complete the remainder of the table(s) that corresponds to the rule. Further instruction as
to which questions should be answered and which questions should not be answered are located in the
“Specific” section of the instruction text. The following is included in this form:
Table 1a - 1f:
Title 40 Code of Federal Regulations Part 60, Subpart DDD: Standards of
Performance for Volatile Organic Compound (VOC) Emissions from the
Polymer Manufacturing Industry
The Texas Commission on Environmental Quality (TCEQ) Regulated Entity Number (RNXXXXXXXXX) and
the application area name from Form OP-1 (Site Information Summary) must appear in the header of each
page for the purpose of identification for the initial submittal. The date of the initial form submittal must also
be included and should be consistent throughout the application (MM/DD/YYYY). Leave the permit
number blank for the initial form submittal. If this form is included as part of the permit revision
process, enter the permit number assigned by the TCEQ, the area name (from Form OP 1), the date of the
revision submittal, and the regulated entity number.
Unit attribute questions that do not require a response from all applicants are preceded by qualification criteria
in the instructions. If the unit does not meet the qualification criteria, a response to the question is not
required. Anytime a response is not required based on the qualification criteria, leave the space
on the form blank.
Notwithstanding any qualification criteria in the form instructions or information provided in
other TCEQ guidance, the applicant may leave an attribute question blank (or indicate “N/A”
for “Not Applicable”) if the attribute is not needed for the applicable requirement
determinations of a regulation for a unit.
In some situations, the applicant has the option of selecting alternate requirements, limitations, and/or
practices for a unit. Note that these alternate requirements, limitations, and/or practices must have the
required approval from the TCEQ Executive Director and/or the U.S. Environmental Protection Agency
Administrator before the federal operating permit application is submitted.
The TCEQ requires that a Core Data Form be submitted on all incoming registrations unless a Regulated Entity
and Customer Reference Number has been issued by the TCEQ and no core data information has changed. If a
Regulated Entity or Customer Reference Number has been issued, then the number must be noted on the
request or applicable form. For more information regarding the Core Data Form, call (512) 239 5175 or go to
the TCEQ Web site at:
www.tceq.texas.gov/permitting/central_registry
TCEQ-10048 (APDG5282v11, 01/14) OP-UA28 Instructions
This form for use by facilities subject to air quality permit requirements and
may be revised periodically (Title V Release 03/03)
Page 1 of 9
OP-UA28 Instructions
Specific:
Table 1a:
Title 40 Code of Federal Regulations Part 60, Subpart DDD: Standards of
Performance for Volatile Organic Compound (VOC) Emissions from the Polymer
Manufacturing Industry
Process ID No.:
Enter the identification number (ID No.) for the polymer manufacturing facility
(maximum 10 characters) as listed on Form OP-SUM (Individual Unit Summary).
SOP Index No.:
Site operating permit (SOP) applicants should indicate the SOP index number for the
unit or group of units (maximum 15 characters consisting of numeric, alphanumeric characters, and/or dashes
prefixed by a code for the applicable regulation [i.e., 60KB XXXX]). For additional information relating to SOP
index numbers, please refer to the TCEQ website at
www.tceq.texas.gov/assets/public/permitting/air/Guidance/Title_V/sop_initial.pdf.
Manufactured Product:
Select one of the following options to describe the product manufactured
by the affected facility. Enter the code on the form.
Code
Description
PROPYL
Polypropylene or polyethylene
STYRENE
Polystyrene
PET
Poly (ethylene terephthalate)
OTHER
The affected facility is not involved with the manufacture of polypropylene, polyethylene,
polystyrene, or poly (ethylene terephthalate)
Note: If “Manufactured Product” is “PROPYL,” “STYRENE,” or “PET,” Form OP-UA12 entitled “Fugitive
Emission Unit Attributes,” Table 5 must be submitted with this application.
Continue only if “Manufactured Product” is “PROPYL,” “STYRENE,” or “PET.”
Continuous Process:
Enter “YES” if the affected facility process is continuous. Otherwise, enter
“NO.”
Complete the rest of Table 1 only if “Continuous Process” is “YES.”
Construction/Modification Date:
Select one of the following options that describes the date of
commencement of the most recent construction, reconstruction, or modification. Enter the code on the form.
Code
Description
87-
On or before September 30, 1987
87-89
After September 30, 1987 and on or before January 10, 1989
89+
After January 10, 1989
Continue only if “Construction/ Modification Date” is “87-89” or “89+.”
Experimental Process Line:
Enter “YES” if the affected facility is an experimental process line.
Otherwise, enter “NO.”
Complete the rest of Table 1 only if “Experimental Process Line” is “NO.”
Complete “Modified after Applicability Date” if “Manufactured Product” is “STYRENE” or
“PET.”
TCEQ-10048 (APDG5282v11, 01/14) OP-UA28 Instructions
This form for use by facilities subject to air quality permit requirements and
may be revised periodically (Title V Release 03/03)
Page 2 of 9
OP-UA28 Instructions
Modified after Applicability Date:
Enter “YES” if the affected facility modified or
reconstructed after its applicability date. Otherwise, enter “NO.”
Complete “Table 2 Threshold Emission Rates” only for processes that meet one of the
following criteria:
1.
“Manufactured Product” is “PROPYL” and “Construction/Modification Date” is
“87-89”; or
2.
“Manufactured Product” is ASTYRENE” or “PET,” and “Modified after Applicability
Date” is “YES.”
Table 2 Threshold Emission Rates:
Select one of the following options to describe the
uncontrolled emission rate. Enter the code on the form.
Code
Description
LESS
The uncontrolled emission rate is less than or equal to the uncontrolled threshold
emission rates in Table 2 of 40 CFR § 60.560
MORE
The uncontrolled emission rate is greater than the uncontrolled threshold emission rates
in Table 2 of 40 CFR § 60.560
Table 1b:
Title 40 Code of Federal Regulations Part 60, Subpart DDD: Standards of
Performance for Volatile Organic Compound (VOC) Emissions from the Polymer
Manufacturing Industry
Complete only if “Manufactured Product” is “STYRENE” or “PET.”
Process ID No.:
Enter the identification number (ID No.) for the polymer manufacturing facility
(maximum 10 characters) as listed on Form OP-SUM entitled “Individual Unit Summary.”
SOP Index No.:
Site operating permit (SOP) applicants should indicate the SOP index number for the
unit or group of units (maximum 15 characters consisting of numeric, alphanumeric characters, and/or dashes
prefixed by a code for the applicable regulation [i.e., 60KB XXXX]). For additional information relating to SOP
index numbers, please refer to the TCEQ website at
www.tceq.texas.gov/assets/public/permitting/air/Guidance/Title_V/sop_initial.pdf.
Complete “Control Device Method” only if “Table 2 Threshold Emission Rates” is “MORE.”
Control Device Modification:
Enter “YES” if the affected facility is controlled by an existing
control device that has been modified, reconstructed, or replaced. Otherwise, enter “NO.”
Complete the rest of Table 1b only for processes that meet one of the following criteria:
1.
“Control Device Modification” is “YES”; or
2.
“Manufactured Product” is “STYRENE” and “Modified after Applicability Date” is
“NO.”
Emergency Vapor Recovery System:
Enter “YES” if emissions are routed through an existing
emergency vapor recovery system (EVRS). Otherwise, enter “NO.”
TCEQ-10048 (APDG5282v11, 01/14) OP-UA28 Instructions
This form for use by facilities subject to air quality permit requirements and
may be revised periodically (Title V Release 03/03)
Page 3 of 9
OP-UA28 Instructions
Complete “EVRS Modification Date” only if “Emergency Vapor Recovery System” is “YES.”
EVRS Modification Date:
Select one of the following options to describe the date which the EVRS
was modified, reconstructed, or replaced. Enter the code on the form.
Code
Description
87-
On or before September 30, 1987
87+
After September 30, 1987
Complete the rest of Table 1 only if “EVRS Modification Date” is “87+.”
Emission Control Method:
Select one of the following options to describe the means by which
total organic compound (TOC) emissions are limited from the material recovery section. Enter the code on the
form.
Code
Description
TOC
Facility limits continuous TOC emissions
OUTLET
Facility limits outlet gas stream temperatures for each final condenser
562A
Facility is choosing to comply with 40 CFR § 60.562-1(a) (1) (I) (A)
562B
Facility is choosing to comply with 40 CFR § 60.562-1(a) (1) (I) (B)
562C
Facility is choosing to comply with 40 CFR § 60.562-1(a) (1) (I) (C)
Complete the rest of Table 1b only if “Emission Control Method” is “TOC,” “562A,” “562B,”
or “562C.”
Control Device:
Select one of the following options to describe the control device of the system. Enter
the code on the form.
Code
Description
ABSORB
An absorber is the final system unit
CONDEN
A condenser is the final system unit
CARBADS
A carbon adsorber is the final system unit
CATINC
Catalytic incinerator
INCIN
Incinerator other than a catalytic incinerator
FLARE
Flare
BOIL150-
Boiler or process heater with a design heat input capacity is less than 150 MMBtu/hr
BOIL150+
Boiler or process heater with a design heat input capacity is greater than or equal to
150 MMBtu/hr
OTHER
Another type of control device is utilized
Control Device ID No.:
Enter the identification number (ID No.) for the control device to which
emissions are routed (maximum 10 characters). This number should be consistent with the control device
identification number listed on Form OP-SUM. If there is no control device, then leave this column blank.
Table 1c:
Title 40 Code of Federal Regulations Part 60, Subpart DDD: Standards of
Performance for Volatile Organic Compound (VOC) Emissions from the Polymer
Manufacturing Industry
Complete Table 1c only if “Manufactured Product” is “PET” and “Modified after
Applicability Date” is “NO.”
Process ID No.:
Enter the identification number (ID No.) for the polymer manufacturing facility
(maximum 10 characters) as listed on Form OP-SUM entitled “Individual Unit Summary.”
TCEQ-10048 (APDG5282v11, 01/14) OP-UA28 Instructions
This form for use by facilities subject to air quality permit requirements and
may be revised periodically (Title V Release 03/03)
Page 4 of 9
OP-UA28 Instructions
SOP Index No.:
Site operating permit (SOP) applicants should indicate the SOP index number for the
unit or group of units (maximum 15 characters consisting of numeric, alphanumeric characters, and/or dashes
prefixed by a code for the applicable regulation [i.e., 60KB XXXX]). For additional information relating to SOP
index numbers, please refer to the TCEQ website at
www.tceq.texas.gov/assets/public/permitting/air/Guidance/Title_V/sop_initial.pdf.
Uses Dimethyl Terephthalate Process:
Enter “YES” if the process line uses the dimethyl
terephthalate process. Otherwise, enter “NO.”
Complete “Esterification Vessels in the Raw Materials Preparation Area” only if “Uses
Dimethyl Terephthalate Process” is “NO.”
Esterification Vessels in the Raw Materials Preparation Area:
Enter “YES” if the
affected facility is the esterification vessels in the raw materials preparation area. Otherwise, enter “NO.”
Complete “Material Recovery Section” only if “Uses Dimethyl Terephthalate Process” is
“YES.”
Material Recovery Section:
Enter “YES” if the affected facility is the material recovery section.
Otherwise, enter “NO.”
Complete “TOC Emissions” only if “Material Recovery Section” is “YES.”
TOC Emissions:
Select one of the following options to describe the TOC limited emissions. Enter the
code on the form.
Code
Description
0.018-
TOC emissions are less than or equal to 0.018 kg TOC per Mg product (0.036 lbs/ton)
0.018+
TOC emissions are greater than 0.018 kg TOC per Mg product (0.036 lbs/ton)
PET Control Device:
Select one of the following options to describe the control device of the system.
Enter the code on the form.
Code
Description
ABSORB
An absorber is the final system unit
CONDEN
A condenser is the final system unit
CARBADS
A carbon adsorber is the final system unit
CATINC
Catalytic incinerator
INCIN
Incinerator other than a catalytic incinerator
FLARE
Flare
BOIL150-
Boiler or process heater with a design heat input capacity less than 150 MMBtu/hr
BOIL150+
Boiler or process heater with a design heat input capacity greater than or equal to
150 MMBtu/hr
OTHER
Another type of control device is utilized
Control Device ID No.:
If applicable, enter the identification number (ID No.) for the control device
to which emissions are routed (maximum 10 characters). This number should be consistent with the control
device identification number listed on Form OP-SUM. If there is no control device, then leave this column
blank.
Complete the rest of Table 1c only if “Material Recovery Section” is “NO” or “Esterification
Vessels in the Raw Materials Preparation Area” is “NO.”
Using Stream-Jet Ejectors:
Enter “YES” if steam-jet ejectors are used. Otherwise, enter “NO.”
TCEQ-10048 (APDG5282v11, 01/14) OP-UA28 Instructions
This form for use by facilities subject to air quality permit requirements and
may be revised periodically (Title V Release 03/03)
Page 5 of 9
